VTEC - CNC DOUBLE COLUMN MACHINING CENTER-VB-3020

Make : VTEC
Year :2008
Model :VB-3020
Control : FANUC 18i-MB
Table size :3,100 x 1,700 mm
Table loading :11,000 kg
X/Y/Z axis travel :3,100/2,000/800 mm
Spindle nose to table :150-950 mm
Dist. between columns : 2,100 mm
Spindle speed :50-4,500 rpm (Gear type)
Spindle motor :18.5 / 22 kw
BT50 / 32ATC
Machine weight :29,500 kg
Machine size :9,780 x 5,755 x 4,043mm
