Radial Drilling Machine-2M55

Whatsapp Us

Machine Name: Radial Drilling Machine-2M55

Manufacturer: Stanko Import

Model: 2M55

Country: USSR

Stock-no.: S04012402

Technical Specifications

Capacity (in Steel) - 55 mm

Drilling Capacity (in CI) - 70 mm

Arm Length - 1800 mm

Spindle Diameter - 90 mm

Spindle Taper - MT 5

Spindle Speeds - 20 rpm to 2000 rpm

Spindle Feed Rate - 0.056 mm/rev to 2.50 mm/rev

Spindle Feed Travel - 400 mm

Vertical Travel of the Arm - 725 mm

Table Size - 605 mm x 450 mm

Clamping Type - Hydraulic   - Table is a Tilting type table. - Hydraulic Gear Shifting & Hydraulic locking of Arm & Drilling Head. - Machine is in excellent working condition.

Radial Drilling Machine-2M55

Send Enquiry
